夹套反应釜（电加热反应釜）（可设计容积：50L-50000L）

详细介绍：反应釜广泛应用于化工、医药、染料、农药、有机合成、石油、食品添加剂和国防工业及科学研究中的反应、蒸发、浓缩、合成、萃取、聚合、矿化等。金宗机械为反应釜设备设计、制造专门企业，积累了二十年反应釜之制造经验，可为用户设计、制造各种型式的反应釜。

金宗机械夹套反应釜加热方式有：蒸汽加热方式，电加热方式，导热油加热方式。

冷却方式有：内盘管冷却方式，夹套冷却方式。

夹套电加热反应釜有加热迅速、耐高温、卫生、无环境污染、勿需锅炉 保温效果好 使用方便等的特点。

电加热不锈钢反应釜操作注意事项：

1、油量为夹套容积的80%左右（以加热器工作时，油不溢出为宜）。

2、严禁无导热油或釜内无物料（及空釜）时通电加热。

3、电加热夹套上部安装放空管要畅通，防止堵塞。

4、电加热升温要缓慢，特别是第一次升温要注意防止引起油气和水气的暴沸。

5、为有效地节约能源，应在设备外加保温层，严禁超压使用。

Capture reaction reactor(electric heating reaction reactor)(designable volume: 50L-5000L)

Introduction: Reactor kettles are widely used in chemical, pharmaceutical, dye, pesticide, organic synthesis, petroleum, food additives, reaction, evaporation, concentration, synthesis, extraction, polymerization, mineralization, etc. in the defense industry and scientific research. Jinzong machinery is a specialized company for the design and manufacture of reaction kettle equipment. It has accumulated 20 years of experience in the manufacture of reaction kettles and can design and manufacture various types of reaction kettles for users.

The heating methods of Jinzong's mechanical jacket reactor include steam heating, electric heating, and thermal oil heating.

The cooling methods are: inner coil cooling method, clamping cooling method.

The electric heating reaction kettle has the characteristics of rapid heating, high temperature resistance, hygiene, no environmental pollution, and no need for boiler insulation to be easy to use.

Attention to the operation of electric heating stainless steel reaction kettle:

1, the amount of oil is about 80 % of the jacket volume(when the heater is working, the oil does not overflow).

2, no heat conduction oil or no material in the kettle(and empty kettle) when energized and heated.

3, electric heating jacket upper installation of the empty tube to smooth, prevent blockage.

The heating up of electric heating should be slow, especially for the first time. Care should be taken to prevent the boiling of oil and gas and water gas.

5, in order to effectively save energy, should be in the equipment plus insulation layer, the use of extreme pressure is strictly prohibited.

技术参数 Technical specifications
